1mm diameter Small Neodymium Disc Magnets Tiny Round Rare Earth Rod Magnets for Sale Crafts Magnets
$4.79 – $10.99
Disc magnets with diameter 1 mm, height from 0.5mm – 5mm
| Material | NdFeB, Grade N35 |
| Shape | Disc / Round |
| Diameter | 1 mm |
| Height | 0.5 mm – 15 mm |
| Tolerance | +/- 0.05 mm |
| Coating | Nickel-plated (Ni-Cu-Ni) |
| Magnetisation | Axial (Poles on Flat Ends) |
| strength | ~ |
| Max. working temperature | 176°F (80°C) |
| Weight(1 piece) | ~ |
1mm diameter Round Small Disc Neodymium N35-N52 Grade Tiny Rare Earth Cylinder Magnets Amazon fro Crafts Magnets where to buy small magnets
These small Neodymium disc magnets are the smallest in our range. When used to attract another magnet, rather than a metal surface such as steel the pull strength between the two magnets will be effectively double creating an incredible pull for their size. Every magnet
is coated with three layers of nickel, copper and nickel to reduce corrosion and provide a smooth and clean finish and are commonly used by universities and research departments to secure tiny parts under a microscope. They are also often used in creative applications, packaging, engineering and manufacturing where small size and maximum strength are required.
| Technical information | |
|---|---|
| Model ID | 1mm Diameter Magnets |
| Material | NdFeB, Grade N35 |
| Shape | Disc / Round |
| Type | Permanent |
| Composite | Neodymium Magnet |
| Diameter | 1 mm |
| Height | 0.5 mm – 15 mm |
| Tolerance | +/- 0.05 mm |
| Coating | Nickel-plated (Ni-Cu-Ni) |
| Magnetisation | Axial (Poles on Flat Ends) |
| Strength | ~ |
| Max. working temperature | 176°F (80°C) |
| Curie temperature | 310 °C |
| weight(1 piece) | ~ |
| Residual magnetism Br | 13700-14200 G, 1.37-1.42 T |
| Coercive field strength bHc | 10.8-12.5 kOe, 860-995 kA/m |
| Coercive field strength iHc | ≥12 kOe, ≥955 kA/m |
| Energy product (BxH)max | 35MGOe |
These discs are incredibly small. They are too difficult to count exactly, so we will make sure you get more than the quantity you order. Even though these discs are tiny, just one or two of these incredible magnets will hold a sheet of 8 1/2″ x 11″ paper to a fridge or filing cabinet.
